LR-1/8-D-O-I-MINI FESTO减压阀:压力控制精准的解决方案
FESTO LR-1/8-D-O-I-MINI 是一款直动式膜片减压阀,专为精确的压力控制而设计,适用于广泛的工业应用场景。
![LR-1/8-D-O-I-MINI FESTO减压阀:压力控制精准的解决方案](https://www.iudustry.com/wp-content/themes/third/themer/assets/images/lazy.png)
产品规格:
- 系列: Mini
- 控制锁: 可锁定旋转手柄
- 安装位置: 可选
- 结构特点: 直动式膜片减压阀
- 控制器功能:
- 输出压力常数
- 主压力补偿功能
- 带二级排气
- 带回流功能
- 符号: 00991559
- 压力表(模拟)或压力显示器(数字): 为 G1/8 准备
工作性能:
- 工作压力: 0.1 Mpa 至 1.6 Mpa (1 bar 至 16 bar)
- 压力调节范围: 0.5 bar 至 12 bar
- 最大压力迟滞: 0.02 Mpa (0.2 bar, 2.9 psi)
- 标准额定流量: 800 l/min (根据 DIN 1343 标准化)
- 工作介质:
- 压缩空气,符合 ISO 8573-1:2010 [7:4:4]
- 惰性气体
- 工作和先导介质说明: 可用润滑介质工作(之后须一直润滑介质工作)
- 油漆湿润缺陷物质(PWIS)符合性: VDMA24364-B1/B2-L
- 输出口空气纯净度等级: 压缩空气,符合 ISO 8573-1:2010 [7:4:4]
- 介质温度: -10 °C 至 60 °C
- 环境温度: -10 °C 至 60 °C
- 产品重量: 300 g
- 安装方式: 面板式安装、管式安装
- 带附件: 气口 1 和 气口 2 均为 G1/8
材料说明:
- RoHS 合规
- 底座材料: 压铸锌
- 密封件材料: NBR
- 外壳材料: 压铸锌
应用领域: FESTO LR-1/8-D-O-I-MINI 减压阀适用于需要精确控制压力的各种工业自动化应用,包括制造业、汽车工业和包装行业。其可靠的压力调节功能和耐用的设计使其在各种恶劣工作环境下表现卓越。
FESTO LR-1/8-D-O-I-MINI 减压阀通过其优异的设计和性能,为工业自动化提供了可靠的压力控制解决方案。无论是现有系统的升级还是新的气动组件集成,该产品都能够提供所需的精度和可靠性。
